VEGABAR 18
Pressure transmitter
With ceramic measuring cell, basic version
|
|
Application area
4 ... 20 mA, thread ½"
VEGABAR 18 is a universal pressure transmitter with 4 ... 20 mA output and ceramic measuring cell for measurement of gases, vapours and liquids up to 100 °C. VEGABAR 18 is an economical solution for a variety of applications in all industrial sectors.
Your benefit
- High plant availability through maximum overload and vacuum resistance of the ceramic measuring cell
- Price-favourable version with small mounting dimensions
Suitable accessories
|
Welded socket VEGABAR series 10, 20, 30 |
| Further accessories | |
Base price
€ 220.00
Detailed information on prices and delivery times can be found in the Configurator.
Staggered Prices
| Quantity | Price |
|---|---|
| from 1 | € 220.00 |
| from 5 | 10 % Discount |
| from 10 | Please contact us! |
Product comparison
Select several products to compare with each other.
Technical specifications
Documentation
Accessories
Configure product
Technical specifications
Measuring range - Pressure
- 0 ... 25 bar [Bar - kPa - psi]
Process temperature
- -40 ... 100 °C [°C - °F]
Accuracy
- 0,5 %
Materials, wetted parts
- 316L
- Ceramic
Threaded connection
- ≥ G½, ≥ ½ NPT
Seal material
- FKM
Protection rating
- IP66/IP67
Output
- 4 … 20 mA
Ambient temperature
- -40 ... 70 °C
Drawing generator
Generate 2D and 3D drawings for your specific configuration.
